Description
800HFRXT6 - Allen-Bradley - 30mm Push-Pull Device 800H PB
This is a 30 mm red push‑pull, twist‑release operator head built for harsh environments with ratings up to NEMA 4/4X/13. It supports a maintained two-position operation and mounts via a 30.5 mm panel hole. The operator features a durable plastic construction and is non‑repairable
TECHNICAL SPECIFICATIONS
General
| Cap Selection | Standard Mushroom Head |
|---|---|
| Type | 30mm Push-Pull Device |
Electrical
| Suitable for illumination | False |
|---|---|
| Operator cap/button shape | Round |
| Operator cap/button material | Plastic |
| Operator cap type | Mushroom head |
Mechanical
| Hole diameter | 30.5 mm |
|---|---|
| Type of electric connection | Screw connection |
| Terminations with finger safe covers | False |
| Operator mechanical design life (cycles, min.) | 250000 |
| Operator cap color | Red |
| Operator cap/button size | 40 mm |
| Enclosure compatibility (NEMA type) | 1, 4, 4X, 12, 13 |
| Operator function | 2-position |
| Operator type | Push-pull unit |
| Operator special function | Maintained with twist release |
| Contact block configuration | No contacts |
| Shock | 25 G (contact fragility)/100 G (no damage) |
| Vibration | 10 G maximum |
Environmental
| Humidity | 50 % |
|---|---|
| Operating temperature | -25 °C |
| Hazardous location rating | False |
| Storage temperature | -40 °C |
Construction
| Operator construction/material | Plastic |
|---|
