Description
800HUR29 - Allen-Bradley - 30mm Potentiometer 800H PB
The 800H-UR29 is a rotary switch designed for tough industrial settings. It offers reliable selection between multiple positions with high mechanical life. Its sealed design ensures protection against harsh elements.
TECHNICAL SPECIFICATION
General
| Type | 30 mm Potentiom Unit |
|---|
Mechanical
| Terminations with finger safe covers | False |
|---|---|
| Enclosure compatibility (NEMA type) | 1, 4, 4X, 12, 13 |
| Hole diameter | 30.5 mm |
| Suitable for illumination | False |
| Operator mechanical design life (cycles, min.) | 25000 |
| Operator function | Single turn |
| Vibration | 10 G maximum |
| Potentiometer module termination wire range | 14 - 18 AWG (x2) |
| Shock | 100 G (no damage) |
| Potentiometer module termination tightening torque | 6 - 7 in-lb / 0.7 - 0.8 N-m |
Electrical
| Potentiometer module power rating | 2 W |
|---|---|
| Potentiometer module input voltage | 300V AC/DC (6V DC min) |
| Potentiometer module resistance rating | 10K Ω |
| Type of electric connection | Screw connection |
Construction
| Operator construction/material | Plastic |
|---|---|
| Operator cap/button shape | Round |
| Operator cap color | Black |
| Operator cap/button material | Plastic |
| Operator cap type | Standard knob |
| Operator type | Potentiom unit |
Environmental
| Hazardous location rating | False |
|---|---|
| Humidity | 50 % |
| Operating temperature | -25 °C |
| Storage temperature | -40 °C |
PRODUCT DATASHEET
