800TJ2 - Allen-Bradley - 30mm Selector Switch 800T PB
Three‑position selector switch operated by a standard knob with maintained action. Fits 30 mm cutout and rated NEMA 4/13, non‑illuminated. Ideal for OFF‑ON‑OFF or similar selector functions.
TECHNICAL SPECIFICATIONS
Mechanical
| Number of switch positions |
3 |
| Hole diameter |
30.5 mm |
| Operator mechanical design life (cycles, min.) |
1000000 |
| Enclosure compatibility (NEMA type) |
1, 4, 12, 13 |
| Operator type |
Selector switch |
| Operator function |
Maintained |
| Shock |
25 G (contact fragility)/100 G (no damage) |
| Vibration |
10 G maximum |
Electrical
| Suitable for illumination |
False |
| Contact block configuration |
No contacts |
Construction
| Terminations with finger safe covers |
False |
| Operator cap/button material |
Plastic |
| Operator construction/material |
Metal |
| Operator cap type |
Standard knob |
| Operator cam code |
Standard cam |
| Operator cap color |
Black with white insert |
Environmental
| Operating temperature |
-25 °C |
| Hazardous location rating |
False |
| Humidity |
50 % |
| Storage temperature |
-40 °C |
PRODUCT DATASHEET
800TJ2
