Description
A200M5CAC - Eaton Cutler Hammer - 270A Three-Pole Freedom NEMA Motor Control Starter
The Eaton A200M5CAC is a Size 5, three-phase, non-reversing Freedom Series motor control starter with a 120 V/60 Hz (or 110 V/50 Hz) coil. It’s rated at 270 A, delivering up to 75 HP at 208 V, 100 HP at 240 V, and 200 HP at 480/600 V, and designed in an open configuration wired for separate control.
GENERAL SPECIFICATIONS
| Product Name |
Eaton A200 NEMA motor control
|
| Catalog Number |
A200M5CAC
|
| UPC |
786678214436
|
| Product Length/Depth |
7.75 in
|
| Product Height |
7.22 in
|
| Product Width |
12 in
|
| Product Weight |
25 lb
|
| Certifications |
UL Listed
CSA Certified |
| Catalog Notes |
For ambient compensated overload relay with auto-reset, add Suffix D.
|
PRODUCT SPECIFICATIONS
| Phase |
Three-phase magnetic
|
| Accessories |
Motor control
|
