Description
BD1515 - Eaton Cutler Hammer - 15-15 A 120V Single-Pole BR Thermal Magnetic Circuit Breaker
Eaton BR thermal magnetic circuit breaker,Type BD 1-Inch CTL plug-on circuit breaker,Includes rejection tab feature,15-15 A,10 kAIC,Single-pole,120V,BD,#14-4 AWG Cu/Al,BD,Type BR Loadcenters.
GENERAL SPECIFICATIONS
| Product Name |
Eaton BR thermal magnetic circuit breaker
|
| Catalog Number |
BD1515
|
| UPC |
786676369053
|
| Product Length/Depth |
2.9 in
|
| Product Height |
2.5 in
|
| Product Width |
1 in
|
| Product Weight |
0.35 lb
|
| Compliances |
Federal Specifications Classification W-C375
|
| Certifications |
UL 489
|
| Catalog Notes |
All Type BD Duplex and BQ Quadplex circuit breakers carry listing for HACR applications. All 15 and 20 ampere single poles are switch duty rated
|
| Product Type |
Thermal magnetic circuit breakers
|
PRODUCT SPECIFICATIONS
| Used with |
Type BR Loadcenters
|
| Amperage Rating |
(2) 15A
|
| Voltage rating |
120 V
|
| Circuit breaker type |
BR
|
| Mounting Method |
Plug-on
|
| Interrupt rating |
10 kAIC
|
| Main circuit breaker |
BD
|
| Wire size |
#14-4 AWG Cu/Al
|
| Number of poles |
Single-pole
|
| Type |
Type BD 1-Inch CTL plug-on circuit breaker
|
| Special features |
Includes rejection tab feature
|
PRODUCT DATASHEET
