Description
E50KL202 - Eaton Cutler Hammer - E50 Nema Heavy Duty Plug-In Limit Switch Operator
The E50KL202 is an adjustable rod lever accessory, featuring a 5.5-inch metal arm with a 0.12-inch diameter roller—designed to interface with E50 side-rotary limit switches in heavy-duty applications applicable down to –10 °C (14 °F) and up to 121 °C (250 °F). Built with stainless steel and meeting UL, CSA, and CE certifications, it ensures dependable performance in harsh environments.
GENERAL SPECIFICATIONS
| Product Name |
Eaton E50 NEMA heavy duty plug-in limit switch operator
|
| Catalog Number |
E50KL202
|
| UPC |
782113290959
|
| Product Length/Depth |
5.5 in
|
| Product Height |
0.38 in
|
| Product Width |
1.12 in
|
| Product Weight |
0.15 lb
|
| Compliances |
RoHS Compliant
CE Marked |
| Certifications |
UL Listed
CSA Certified CE |
PRODUCT SPECIFICATIONS
| Used with |
Used with side rotary
|
| Type |
Accessory
|
| Actuator |
Adjustable rod
|
| Series |
E50
|
| Operating temperature - max |
200 °F
|
| Operating temperature - min |
10 °F
|
| Environmental rating |
NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
|
| Material |
Metal
|
PRODUCT DATASHEET
