Description
E51RC - Eaton Cutler Hammer - 120 V E51 Nema Limit Switch Inductive Proximity Sensor
The E51RC serves as a four-wire (AC) receptacle for assembled E51 sensor modules, providing terminal wiring in a die-cast zinc housing. It shares the same ½-inch NPT conduit interface and environmental resilience, making sensor installation robust and dependable. Compatible with various sensor heads, it simplifies wiring in modular configurations.
GENERAL SPECIFICATIONS
| Product Name |
Eaton E51 NEMA limit switch inductive proximity sensor
|
| Catalog Number |
E51RC
|
| UPC |
782113107202
|
| Product Length/Depth |
2.92 in
|
| Product Height |
1.06 in
|
| Product Width |
1.54 in
|
| Product Weight |
0.45 lb
|
| Certifications |
UL Listed
CSA Certified |
PRODUCT SPECIFICATIONS
| Type |
Assembled Inductive Proximity Fiber Optic Sensor
|
| Enclosure material |
Die cast zinc
|
| Connection |
Screw terminal
|
| Series |
E51
|
| Number of wires |
4
|
| Environmental rating |
NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP67
|
| Operating temperature - max |
158 °F
|
| Operating temperature - min |
-13 °F
|
| Operating voltage |
120 Vac
|
