FDB3040L - Eaton Cutler Hammer - 40A Series C Complete Molded Case Circuit Breakers
The Eaton FDB3040L is a three-pole, Series C, F-Frame molded-case circuit breaker featuring a fixed thermal-magnetic trip (type T186). Rated for 40 A, it supports 600 VAC or 250 VDC systems and offers interrupt capacities of 18 kA at 240 VAC and 14 kA at 480 VAC, with line-and-load terminal configuration for flexible panel integration.
GENERAL SPECIFICATIONS
| Product Name |
Eaton Series C complete molded case circuit breaker
|
| Catalog Number |
FDB3040L
|
| UPC |
786679305928
|
| Product Length/Depth |
3.38 in
|
| Product Height |
6 in
|
| Product Width |
4.13 in
|
| Product Weight |
4.5 lb
|
| Certifications |
UL Listed
|
| Product Type |
Molded case circuit breaker
|
PRODUCT SPECIFICATIONS
| Amperage Rating |
40 A
|
| Voltage rating |
600 Vac, 250 Vdc
|
| Trip Type |
T186
|
| Circuit breaker type |
FDB
|
| Circuit breaker frame type |
Complete breaker
|
| Series |
Series C
|
| Terminals |
Line and load
|
| Frame |
F
|
| Frequency rating |
50/60 Hz
|
| Interrupt rating |
18 kAIC at 240 Vac
14 kAIC at 480 Vac |
| Number of poles |
Three-pole
|
