FH17 - Eaton Cutler Hammer - 1.25A A200/B100 Heater
The Eaton FH17 A200/B100 heater is designed for NEMA Starter Sizes 0, 1, and 2. It supports ambient full-load currents in the 1.01–1.28 A range, making it suitable for precise motor protection. Built with Type A and B overload relays, it offers reliable thermal and fast-trip operation.
GENERAL SPECIFICATIONS
| Product Name |
Eaton A200/B100 heater
|
| Catalog Number |
FH17
|
| UPC |
786678629384
|
| Product Length/Depth |
2.1 in
|
| Product Height |
0.8 in
|
| Product Width |
1.3 in
|
| Product Weight |
0.03 lb
|
| Certifications |
CSA Certified
UL Listed |
| Catalog Notes |
Select heater coils based on full load current(FLA) shown on motor nameplate. Heater coils are rated to protect 40 degree C rise and a service factor of 1.15, Single-Phase requires 2 heaters, Three-Phase Requires 3 heaters
|
| Global Catalog |
FH17
|
PRODUCT SPECIFICATIONS
| Special features |
Used with Starter Sizes 0,1, and 2
|
| Type |
A200/B100 Heater
|
| Used with |
Used with Starter Sizes 0,1, and 2
|
| Design |
NEMA
|
| Full load current range |
Ambient 1.01-1.11, 1.17-1.28 A, Non-Comp 0.94-1.03, 1.14-1.25 A
|
| Overload relay |
Type A and B
|
| Trip type |
Thermal and fast trip
|
