Description
GHB1100 - Eaton Cutler-Hammer - Bolt-On 100 Amp 1 Pole 480 Volt Molded Case Circuit Breaker
Eaton Series C complete molded case circuit breaker, G-frame, GHB, Complete breaker, Fixed thermal, Fixed magnetic trip type, Single-pole, 100 A, 277 Vac, 125 Vdc, 14 kAIC at 277 Vac, 50/60 Hz
GENERAL SPECIFICATIONS
| Product Name |
Eaton Series C complete molded case circuit breaker
|
| Catalog Number |
GHB1100
|
| UPC |
786679021774
|
| Product Length/Depth |
2.63 in
|
| Product Height |
4 in
|
| Product Width |
1 in
|
| Product Weight |
0.9 lb
|
| Compliances |
Federal Specifications Classification W-C375B
|
| Certifications |
UL Listed
|
PRODUCT SPECIFICATIONS
| Type |
Molded case circuit breaker
|
| Amperage Rating |
100 A
|
| Voltage rating |
277 Vac, 125 Vdc
|
| Trip Type |
T186
|
| Circuit breaker type |
GHB
|
| Circuit breaker frame type |
Complete breaker
|
| Series |
Series C
|
| Frame |
G
|
| Frequency rating |
50/60 Hz
|
| Interrupt rating |
14 kAIC at 277 Vac
|
| Number of poles |
Single-pole
|
