Description
HMCPE100R3C - Eaton Cutler Hammer - 100A Three-Pole Motor Circuit Protector
Eaton molded case circuit breaker accessory motor protection, Motor circuit protector, 100 A, Three-pole, 480 V, Adjustable, Frame J-K, 300-1000 A, 600 Y/347 V, Series G, Non-aluminum
GENERAL SPECIFICATIONS
| Product Name |
Eaton molded case circuit breaker accessory motor protection
|
| Catalog Number |
HMCPE100R3C
|
| UPC |
786679113691
|
| Product Length/Depth |
2.99 in
|
| Product Height |
5.5 in
|
| Product Width |
3 in
|
| Product Weight |
3 lb
|
| Compliances |
Contact Manufacturer
|
| Certifications |
UL Listed
CSA Certified |
| Global Catalog |
HMCPE100R3C
|
| Product Type |
Molded case circuit breaker accessory
|
PRODUCT SPECIFICATIONS
| Amperage Rating |
100 A
|
| Voltage rating |
480 V
|
| Trip Type |
T98
|
| Frame size |
Frame J-K
|
| Magnetic trip range |
300-1000 A
|
| Voltage - max |
600 Y/347 V
|
| Series |
Series G
|
| Terminal material |
Non-aluminum
|
| Number of poles |
Three-pole
|
| Type |
Motor circuit protector
|
PRODUCT DATASHEET
