Description
JXD63B300 - Siemens - Bolt-On 300 Amp 3 Pole 600 Volt Molded Case Circuit Breakers
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP UNIT. STANDARD 40 DEG C BREAKER JD FRAME WITH STANDARD BREAKING CAPACITY AND NON-INTERCHANGEABLE TRIP. MEETS UL 489 / IEC 60947-2 STANDARDS. 300A 3-POLE BREAKER (25KAIC AT 600V) (35KAIC AT 480V). SPECIAL FEATURES: NO LUGS INSTALLED. DIMENSIONS (W x H x D) IN: 7.5 x 11 x 4.
GENERAL SPECIFICATIONS
| EAN | Not available |
| UPC | 783643213074 |
| Commodity Code | 85362099 |
| LKZ_FDB/ CatalogID | LV10.1 |
| Product Group | 3741 |
| Group Code | P360 |
| Country of origin | Mexico |
| Compliance with the substance restrictions according to RoHS directive | Since: 07/14/2008 |
| Returnable | Yes |
| WEEE (2012/19/EU) Take-Back Obligation | Yes |
PRODUCT DATASHEET
