Description
10250T197LGP2A - Eaton Cutler-Hammer Push Button
Eaton Heavy-duty watertight and oiltight selector switch, Heavy-duty watertight and oiltight, Standard actuator, LED, Full voltage, NEMA 3, 3R, 4, 4X, 12, 13, Green, Plastic, 120 V, 30.5 mm
GENERAL SPECIFICATIONS
| PRODUCT NAME | Eaton 10250T pushbutton |
| CATALOG NUMBER | 10250T197LGP2A |
| UPC | 782114711156 |
| PRODUCT LENGTH/DEPTH | 2.4 in |
| PRODUCT HEIGHT | 3.2 in |
| PRODUCT WIDTH | 2.1 in |
| PRODUCT WEIGHT | .4 lb |
| COMPLIANCES | CE Marked |
| CERTIFICATIONS | UL Listed CSA Certified |
PRODUCT SPECIFICATIONS
| LIGHT UNIT TYPE | LED, full voltage |
| SERIES | 10250T |
| TYPE | Heavy-Duty Watertight/Oiltight |
| LIGHT UNIT VOLTAGE | 120 Vac |
| RATING |
NEMA 4X NEMA 12 NEMA 3R NEMA 13 NEMA 4 NEMA 3 |
| LENS MATERIAL | Plastic |
| STYLE | 30.5 mm |
| LENS COLOR | Green |
| ACTUATOR | Standard |
