Description
10250TJ63 - Eaton Cutler-Hammer - 65mm Non-illuminated Push-Pull Operator Pushbutton
Heavy-Duty 30.5 mm non-illuminated push-pull operator with a jumbo red mushroom head labeled "E-STOP". Anodized aluminum body, built to be watertight/oiltight and NEMA rated for rugged environments. UL Listed and CSA Certified, measuring 65 mm cap size.
GENERAL SPECIFICATIONS
| Product Name |
Eaton 10250T pushbutton button
|
| Catalog Number |
10250TJ63
|
| UPC |
782113143620
|
| Product Length/Depth |
2.4 in
|
| Product Height |
3.3 in
|
| Product Width |
2.1 in
|
| Product Weight |
0.1 lb
|
| Compliances |
CE Marked
|
| Certifications |
UL Listed
CSA Certified |
| Catalog Notes |
Not suitable for use in ultraviolet light applications
|
| Product Type |
Pushbutton accessory
|
PRODUCT SPECIFICATIONS
| Used with |
Push-pull, non-illuminated
|
| Type |
30.5 mm, Heavy-Duty Watertight/Oiltight
|
| Actuator color |
Red
|
| Bus material |
Anodized aluminum
|
| Actuator |
Jumbo mushroom head
|
| Series |
10250T
|
| Legend |
EMERGENCY STOP
|
| Product category |
Button
|
| Size |
65 mm
|
PRODUCT DATASHEET
