Description
Specifications
| Main | |
| Product | Manual Starter |
|---|---|
| Type | M |
| NEMA Size | M-0 |
| Complementary | |
| Control Unit | Push-button |
| Pilot Light | No indicator |
| Horsepower Rating | 3 hp 200...230 V AC, 3 phase 5 hp 380...575 V AC, 3 phase |
| Voltage Rating | 600 V AC |
| Number of Poles | 3P |
| Starter Type | Non reversing |
| Electrical Connection | Pressure wire clamp |
| Overload Relay Type | Melting alloy |
| Number of Thermal Units Required | 3 |
| Wire Gauge | 14 AWG...8 AWG copper |
| Auxiliary Contacts | Without |
| Environment | |
| Height | 10.34 in (262.64 mm) |
| Width | 5.13 in (130.30 mm) |
| Depth | 5.78 in (146.81 mm) |
| Certifications | UL listed file E42243 CCN NLRV CSA LR60905 class 3211 05 |
| NEMA Enclosure Rating | NEMA 4X glass polyester |
| Ordering and shipping details | |
| Category | US10CP121103 |
| Discount Schedule | 0CP1 |
| GTIN | 785901821014 |
| Returnability | Yes |
| Country of origin | MX |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 6.3 in (16.0 cm) |
| Package 1 Width | 6.8 in (17.3 cm) |
| Package 1 Length | 11.4 in (29.0 cm) |
| Package weight (Lbs) | 5.58 lb (US) (2.53 kg) |
| Contractual warranty | |
| Warranty (in months) | 18 |
