700HG47A1 - Allen-Bradley - 120V 50/60Hz Open Style Power Relay
700-HG47A1 - A power relay from the Bulletin 700-HG series that switches DC or AC loads with various contact configurations, suitable for industrial control panels.
TECHNICAL SPECIFICATIONS
Electrical
| Number of contacts as normally open contact |
2 |
| Nominal current |
40 A |
| Complete with socket |
False |
| With LED indication |
False |
| Voltage type for actuating |
AC |
| Rated control supply voltage at AC 50 Hz |
120 V |
| Rated control supply voltage at AC 60 Hz |
120 V |
| Type of electric connection |
Screw connection |
| Rated thermal current (Ith) |
40 A |
Mechanical
| With detachable clamps |
False |
| With forced-guided contacts |
False |
| Degree of protection (IP) |
IP00 |
Construction
| Width |
63.5 mm |
| Height |
79.4 mm |
| Depth |
58.7 mm |
| Contact material |
AgCdO |
| Material of contact surface |
Other |
Environmental
| Operating temperature |
-30 degC |
| Storage temperature |
-30 degC |
PRODUCT DATASHEET
700HG47A1
