Description
"
Specifications
| Main | |
| Product or Component Type | Mechanically Held Lighting Contactor |
|---|---|
| Range of Product | 8903LX |
| Control Circuit | Separate control circuit |
| Complementary | |
| Control Voltage | 110 V AC 50 Hz 120 V AC 60 Hz |
| Inrush power in VA | 150 VA 60 Hz 140 VA 50 Hz 25 VA 50/60 Hz |
| Current Rating | 20 A tungsten 30 A fluorescent |
| Number of Poles | 2P 2 NO |
| Control Unit | No control units |
| Pilot Light | No indicator |
| Other Options | None |
| Electrical Connection | Screw-clamp terminals |
| Height | 8.8 in (224 mm) |
| Depth | 3.3 in (83 mm) |
| Width | 2.9 in (73 mm) |
| Environment | |
| Enclosure Type | Not rated (open device) |
| Product Certifications | UL Listed CSA |
| Ordering and shipping details | |
| Category | US10CP121322 |
| Discount Schedule | 0CP1 |
| GTIN | 785901057239 |
| Returnability | Yes |
| Country of origin | MX |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 4.50 in (11.43 cm) |
| Package 1 Width | 7.400 in (18.796 cm) |
| Package 1 Length | 10.50 in (26.67 cm) |
| Package weight (Lbs) | 4.601 lb (US) (2.087 kg) |
| Compliance | |
| Compliance | TAA Compliant |
| Contractual warranty | |
| Warranty (in months) | 18 |
