Description
| Main | |
|---|---|
| Product | Mechanically Held Lighting Contactor |
| Type | S |
| Complementary | |
| Control Circuit Voltage | 120 V AC 60 Hz110 V AC 50 Hz |
| Current Rating | 60 A |
| Number of Poles | 3P |
| Control Units | No control units |
| Pilot Light | Without pilot light |
| Auxiliary Contacts | Without |
| Other Options | None |
| Electrical Connection | Lugs |
| Height | 7.8 in (198 mm) |
| Depth | 5.2 in (133 mm) |
| Width | 4.6 in (117 mm) |
| Environment | |
| Enclosure Type | Not rated (open device) surface none |
| Product Certifications | UL ListedCSA |
| Ordering and shipping details | |
| Category | US10CP121324 |
| Discount Schedule | 0CP1 |
| GTIN | 785901102489 |
| Returnability | Yes |
| Country of origin | MX |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 8.400 in (21.336 cm) |
| Package 1 Width | 8.300 in (21.082 cm) |
| Package 1 Length | 12.200 in (30.988 cm) |
| Package weight(Lbs) | 8.801 lb(US) (3.992 kg) |
| Compliance | |
| Compliance | TAA Compliant |
| Contractual warranty | |
| Warranty (in months) | 18 |
Product Datasheet
8903SPO11V02
