9001K93B - Schneider Electric - 57mm Square D Mushroom Pushbutton
The 9001K93B from Schneider Electric is a robust 57mm blue mushroom-style pushbutton from the Square D range, ideal for emergency or control use. Its oversized head allows quick access, making it suitable for industrial machinery panels and safety stations. Built for reliability, it supports efficient operator control.
GENERAL SPECIFICATIONS
| Range of Product | Harmony 9001K Harmony 9001SK |
|---|---|
| Product or Component Type | Mushroom button |
| Device short name | 9001K |
| Accessory / separate part destination | Push-button |
| Device presentation | Basic element |
| Bezel material | Plastic |
|---|---|
| Overvoltage category | Class II conforming to IEC 61140 |
| Operating position | Any position |
| Shape of signaling unit head | Round |
| Operator profile | Black mushroom Ø 35 mm |
| Width | 1.6 in (40 mm) |
| Height | 1.6 in (40 mm) |
| Depth | 4.6 in (116 mm) |
| Mounting diameter | 1.2 in (30 mm) |
| Cap/operator or lens colour | Black |
| Net Weight | 0.311 lb(US) (0.141 kg) |
| Protective treatment | TC |
|---|---|
| Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient air temperature for operation | -13…158 °F (-25…70 °C) |
| IP degree of protection | IP65/IP66 |
| NEMA degree of protection | NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3R NEMA 4 NEMA 6 |
| Standards | IEC 60204-1, for emergency stop devices if used with emergency stop legend plate type 9001KN ISO 13850, for emergency stop devices if used with emergency stop legend plate type 9001KN IEC 60947-5-1 IEC 60947-1 IEC 60947-5-4 JIS C 4520 JIS C 852 UL 508 CSA C22.2 No 14 |
| Product Certifications | NEMA UL 508 |
| Mechanical durability | 5000000 cycles |
| Vibration resistance | 7 gn (f= 2…500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 50 gn IEC 60068-2-27 |
| Category | US10CS121433 |
|---|---|
| Discount Schedule | 0CS1 |
| GTIN | 785901174059 |
| Returnability | No |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 7.62 in (19.355 cm) |
| Package 1 Width | 3.00 in (7.62 cm) |
| Package 1 Length | 19.35 in (49.161 cm) |
| Package 1 Weight | 1.600 oz (45.359 g) |
