Description
9001KM38 - Schneider Electric - Square D Motor Control Part And Accessory
This light block with integral resistance provides clear visual feedback on the status of your machines It is clearly distinguishable visually at a distance due illumination via integral LED, enabling complex machine statuses to be read at a glance It works at a rated voltage of 120V. It is impact resistant, dust resistant, and vibration resistant thanks to its IP20, making it ideal for operation in harsh environments
GENERAL SPECIFICATIONS
| Range of Product | Harmony 9001K Harmony 9001SK |
|---|---|
| Product or Component Type | Light block |
| Device short name | 9001K |
| Bulb base | BA 9s |
| Light block supply | Direct via integral resistance |
| Net Weight | 0.11 lb(US) (0.05 kg) |
|---|---|
| Light source | Incandescent bulb |
| [Us] rated supply voltage | 120 V AC/DC |
| [Us] Rated supply voltage | 120 V |
| Light block supply | Full voltage or resistor |
| Size | 30 mm |
| Protective treatment | TC |
|---|---|
| Ambient Air Temperature for Storage | -40…158 °F (-40…70 °C) |
| Ambient air temperature for operation | -13…158 °F (-25…70 °C) |
| IP degree of protection | IP10 IEC 60529 |
| Standards | IEC 60947-5-1 UL 508 IEC 60947-5-4 IEC 60947-1 CSA C22.2 No 14 JIS C 852 JIS C 4520 |
| Product Certifications | NEMA UL 508 |
| Electrical shock protection class | Class II IEC 61140 |
| Vibration resistance | 7 gn (f= 2…500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 50 gn IEC 60068-2-27 |
| Category | US10CS121435 |
|---|---|
| Discount Schedule | 0CS1 |
| GTIN | 3389110918557 |
| Returnability | Yes |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.20 in (5.588 cm) |
| Package 1 Width | 3.70 in (9.398 cm) |
| Package 1 Length | 2.00 in (5.080 cm) |
| Package 1 Weight | 2.240 oz (63.500 g) |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 50 |
| Package 2 Height | 11.81 in (30.000 cm) |
| Package 2 Width | 11.81 in (30.000 cm) |
| Package 2 Length | 15.75 in (40.000 cm) |
| Package 2 Weight | 9.083 lb(US) (4.120 kg) |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 400 |
| Package 3 Height | 29.53 in (75.000 cm) |
| Package 3 Width | 31.50 in (80.000 cm) |
| Package 3 Length | 23.62 in (60.000 cm) |
| Package 3 Weight | 90.301 lb(US) (40.960 kg) |
