9001SKRU10 - Schneider Electric - Square D Push Button with LED Light
Roll over image to zoom in Click on image to zoom
9001SKRU10 - Schneider Electric - Square D Push Button with LED Light

9001SKRU10 - Schneider Electric - Square D Push Button with LED Light

Square DSKU: SQD9001SKRU10
Price:
$122.45
Stock:
Sold out

Description

9001SKRU10 - Schneider Electric - Square D Push Button with LED Light

The 9001SKRU push buttons are for use in 9001SKYP pendant stations. This line of yellow pendant stations consists of polymeric enclosures that will hold up to 10 push button operators. Type SKRU push buttons have a plastic operator that mounts in a 1.18 inch round hole. This push button consists of two momentary push button operators that are not interlocked. One operator has a no guard ring not with a black insert and a normally open contact. The other operator has a no guard ring nut with a red insert and a normally closed contact. Contact blocks have a UL Type A600, UL Type Q600 and a 10A resistive VAC rating. The contacts in these contact blocks are double break. Contact blocks will accept up to two 12AWG to 24 AWG solid or stranded wires. The contact block terminals are protected to meeting VDE 0106 Part 100. When properly installed this opertor is UL listed for Types 1, 2, 3, 3R, 4, 4X, 6, 12 and 13 environments. This operator is UL Listed and CSA certified. "It is installed into a Ø 30mm panel cutout." "The modular range of Ø 30mm plastic control and signaling provides robust and reliable solutions for a wide range of heavy industry applications.


GENERAL SPECIFICATIONS

Main
Range of Product Harmony 9001SK
Product or Component Type Push-button
Device short name 9001SK
Complementary
Bezel material Plastic
Mounting diameter 1.2 in (30 mm)
Contact operation Standard
Mechanical durability 5000000 cycles
Device presentation Basic element
Environment
Standards UL 508
IEC 60947-5-1
JIS C 852
IEC 60947-5-4
IEC 60947-1
JIS C 4520
CSA C22.2 No 14
IP degree of protection IP65/IP66
NEMA degree of protection NEMA 3R/4X/13
Ordering and shipping details
Category US10CS121431
Discount Schedule 0CS1
GTIN 785901526742
Returnability No
Country of origin MX
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 1.89 in (4.801 cm)
Package 1 Width 2.21 in (5.601 cm)
Package 1 Length 3.70 in (9.401 cm)
Package 1 Weight 3.840 oz (108.862 g)



PRODUCT DATASHEET

9001SKRU10_Product Datasheet
