Description
9080GA6 - Schneider Electric - Square D Linergy Terminal Block
Square D 2510M and T integral horsepower manual motor starters provide overload protection and On Off control for small AC motors. Starters can be locked in the Off or Stop position to prevent inadvertent operation. Pilot lights and auxiliary contacts are field addable. Overload heater elements are ordered separately to match motor data. A variety of enclosures are available. Starters are UL Listed and CSA Certified for global applications.
GENERAL SPECIFICATIONS
| Range of Product | 9080G |
|---|---|
| Product Type | Terminal block |
| Localisation on Device | Standard |
| Color | Natural |
| Quantity | Set of 50 |
| Voltage Rating | 600 V AC/DC |
|---|---|
| Current Rating | 40 A UL 40 A CSA |
| Wire Size | AWG 22...AWG 12 copper |
| Mounting Type | 9080GH track 35 mm DIN rail |
| Certifications | CE UL recognized E60616 CCN XCFR2 CSA file 62144 class 6228 01 |
| Protection Type | Fingersafe DIN 57470 |
| Electrical Connection | ring tongue |
| Material | Nylon: block Tin plated brass: busbar |
| Ambient air temperature for operation | -40…125 °C (-40…257 °F) |
| Electrical Connrection Tightening Torque | Screw terminal zinc plated steel 18…20 lbf.in (2.03…2.3 N.m) : AWG 22...AWG 12 copper) |
| Height | 1.48 in (37.59 mm) |
| Width | 1.8 in (45.7 mm) |
| Depth | 0.37 in (9.40 mm) |
| Density | 32 per foot |
| Compatible End Barrier | GP6B |
| Category | US10CP521702 |
|---|---|
| Discount Schedule | 0CP5 |
| GTIN | 785901154952 |
| Returnability | Yes |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1.3 in (3.3 cm) |
| Package 1 Width | 0.40 in (1.0 cm) |
| Package 1 Length | 1.8 in (4.6 cm) |
| Package 1 Weight | 0.3 oz (9.1 g) |
