Description
9080GC6 - Schneider Electric - 110 Amp 600 Volt Square D Terminal Block
Square D 2510M and T integral horsepower manual motor starters provide overload protection and On Off control for small AC motors. Starters can be locked in the Off or Stop position to prevent inadvertent operation. Pilot lights and auxiliary contacts are field addable. Overload heater elements are ordered separately to match motor data. A variety of enclosures are available. Starters are UL Listed and CSA Certified for global applications.
GENERAL SPECIFICATIONS
| Range of Product | 9080G |
|---|---|
| Product Type | Terminal block |
| Localisation on Device | Standard |
| Color | Natural |
| Quantity | Set of 50 |
| Voltage Rating | 600 V AC/DC |
|---|---|
| Current Rating | 110 A UL 85 A CSA |
| Wire Size | AWG 18...AWG 4 copper |
| Mounting Type | 35 mm DIN rail 9080GH track |
| Certifications | CE CSA file 62144 class 6228 01 UL recognized E60616 CCN XCFR2 |
| Electrical Connection | Zinc plated steel box lugs |
| Material | Nylon: block Tin plated brass: busbar |
| Ambient air temperature for operation | -40…125 °C (-40…257 °F) |
| Electrical Connrection Tightening Torque | Lug zinc plated steel 32…35 lbf.in (3.6…4.0 N.m) : AWG 18...AWG 4 copper) |
| Height | 2.13 in (54.10 mm) |
| Width | 1.99 in (50.55 mm) |
| Depth | 0.43 in (10.92 mm) |
| Density | 28 per foot |
| Compatible End Barrier | GC6B |
| Category | US10CP521702 |
|---|---|
| Discount Schedule | 0CP5 |
| GTIN | 785901155065 |
| Returnability | Yes |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 7.62 in (19.355 cm) |
| Package 1 Width | 3.00 in (7.62 cm) |
| Package 1 Length | 19.355 in (49.161 cm) |
| Package 1 Weight | 0.80 oz (22.68 g) |
PRODUCT DATASHEET
