9998LX55 - Schneider Electric - Square D 8903L Contactor
The 9998LX55 is a replacement unlatch coil designed for use with Square D 8903L mechanically held lighting contactors (2 to 12 poles). It operates on 277V AC, 60Hz, providing reliable performance for lighting control systems. This coil ensures proper unlatching function, enabling automatic release of the contactor when required. Ideal for maintenance or repair of existing lighting contactor assemblies, it maintains compatibility with Schneider Electric's legacy 8903L series.
GENERAL SPECIFICATIONS
Main
| Product or Component Type |
Coil |
| Accessory / separate part destination |
Class 8903 contactor |
Complementary
| [Ue] rated operational voltage |
277 V AC 60 Hz |
| Inrush power in VA |
180 VA |
| Height |
1.8 in (44.5 mm) |
| Width |
2.5 in (62.5 mm) |
| Depth |
1.1 in (28.7 mm) |
Ordering and shipping details
| Category |
US1CP1021756 |
| Discount Schedule |
CP10 |
| GTIN |
785901057703 |
| Returnability |
Yes |
Packing Units
| Unit Type of Package 1 |
PCE |
| Nbr. of units in pkg. |
1 |
| Package 1 Height |
1.300 in (3.302 cm) |
| Package 1 Width |
2.300 in (5.842 cm) |
| Package 1 Length |
3.100 in (7.874 cm) |
| Package weight(Lbs) |
3.52 oz (99.79 g) |
PRODUCT DATASHEET
9998LX55_Product Datasheet
