Description
9998SO1 - Schneider Electric - Square D Contactor and Motor Starter Auxiliary
Type S melting alloy thermal overload relays provide motor overcurrent protection. The exclusive one piece melting alloy thermal unit is used in these relays provide protection against overheating of the motor winding insulation due excessive over current. This replaceable standard NC output contact of the overload relay comes as standard with all Type S melting alloy overload relays. Contact module has a NEMA B600 contact rating with a maximum voltage rating of 600VAC.
GENERAL SPECIFICATIONS
| Product or Component Type | Accessory |
|---|---|
| Accessory / separate part destination | starter |
| NEMA size | 00 0 1 2 3 4 5 6 |
|---|---|
| Number of poles | 1 |
| Category | US10CP121751 |
|---|---|
| Discount Schedule | 0CP1 |
| GTIN | 785901754732 |
| Returnability | Yes |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1.30 in (3.3 cm) |
| Package 1 Width | 2.28 in (5.8 cm) |
| Package 1 Length | 3.11 in (7.9 cm) |
| Package 1 Weight | 1.0 oz (27.2 g) |
