9999S2 - Schneider Electric - Square D Type S NEMA Combination Starter
8538 Type S combination starters combine the requirements of motor overload and short circuit protection into one package. 8538 Type S combination starters can be furnished with either a fusible or nonfusible disconnect switch. Class 8538 combination starters are available in NEMA Size 0 through 6. This replacement fuse clip kit is for 8538S pre series D and 8738S pre series E combination starters. Fuse clip kit is for NEMA size 0 or 1 combination starters or 30 A lighting contactors. The replacement fuse clip kit is for class H fuses up to 30 A and up to 600V.
GENERAL SPECIFICATIONS
Main
| Product Range |
8538/8738 |
| Component type |
Fuse Clip Kit |
| Used with |
starter |
Complementary
| Fuse type |
H |
Environment
| Product Certifications |
UL Listed |
Ordering and shipping details
| Category |
US10CP121761 |
| Discount Schedule |
0CP1 |
| GTIN |
785901813620 |
| Returnability |
No |
| Country of origin |
MX |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
2.60 in (6.604 cm) |
| Package 1 Width |
3.10 in (7.874 cm) |
| Package 1 Length |
4.80 in (12.192 cm) |
| Package 1 Weight |
3.52 oz (99.79 g) |
PRODUCT DATASHEET
9999S2_Product Datasheet
