Description
| Main | |
|---|---|
| Range of Product | PowerPact MPowerPact P |
| Product or Component Type | Mechanical lug |
| Accessory / separate part category | Connection accessory |
| Quantity per Set | Set of 1 |
| Complementary | |
| Line Rated Current | 800…1200 A |
| Material | Aluminium |
| Mounting Mode | Unit mountI-Line |
| Location of connection | Downstream |
| AWG gauge | 3/0 AWG...500 kcmil aluminium |
| Kcmil size | 500 kcmil |
| Tightening torque | 442.5 lbf.in (50 N.m) 0.1…0.4 in² (95…240 mm²) (3/0 AWG...500 kcmil) |
| Environment | |
| Product Certifications | CSAUL |
| Ordering and shipping details | |
| Category | US10DE201250 |
| Discount Schedule | 0DE2 |
| GTIN | 785901682936 |
| Returnability | Yes |
| Country of origin | US |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 3.000 in (7.620 cm) |
| Package 1 Width | 6.600 in (16.764 cm) |
| Package 1 Length | 7.300 in (18.542 cm) |
| Package weight(Lbs) | 8.960 oz (254.012 g) |
| Contractual warranty | |
| Warranty (in months) | 18 |
Product Datasheet
AL1200P24K
AL1200P24K
