Description
GENERAL
| Application | Wire Termination |
| Catalog Number | AYP750 |
| Color Code | Yellow |
| Connector Type | INLINE PIN |
| Die Index | 936 |
| Finish Type | Tin-Plated |
| Insulation | Y |
| Insulation Type | EPDM Rubber |
| Material | Aluminum |
| Physical Attribute - Number of Crimps Required | 3 |
| Pin Type | Solid |
| Plated | Yes |
| Plating Type | Tin |
| Product Family | COMPRESSION |
| Product Type | Terminal |
| Sub Brand | HYPLUG |
| Temperature Rating | 194 |
| Terminal Type | Pin |
| Trade Name | HYPLUG™ |
| Type | Aluminum Pin Adapters |
| UPC | 781810737781 |
| UPC 14 Digit GTIN | 00781810737781 |
DIMENSIONS
| Dimension - A Outside Diameter inch | 1.46 in |
| Dimension - B Length fraction | 1-5/8 in |
| Dimension - B Length inch | 1.59 in |
| Dimension - B Outside Diameter inch | 0.81 in |
| Dimension - L Length Overall mm | 96 mm |
| Dimension - Length Overall inch | 3.79 in |
| Dimension - P inch | 1.76 in |
| Dimension - Strip Length inch | 1-3/4 |
| Dimensions | 4.16 in x 1.46 in x 1.46 in |
| Equivalent Pin Size | 500 kcmil |
| Height | 1.46 in |
| Length | 4.16 in |
| Package Height | 0 in |
| Package Length | 0 in |
| Package Weight | 0 lb |
| Package Width | 0 in |
| Width | 1.46 in |
ELECTRICAL RATINGS
| Voltage - Maximum | 35000 V |
| Voltage Rating | 35 kV |
CONDUCTOR RELATED
| Conductor - AL Str Size | 750 KCMIL |
| Conductor - AL Str Size Range | 750 kcmil |
| Conductor - Copper DLO Size | 535 KCMIL |
| Conductor - Copper DLO Size Range | 535 kcmil |
| Conductor - Copper Flex I Size | - |
| Conductor - Copper Str Compact Size | 750 KCMIL |
| Conductor - Copper Str Size | 750 KCMIL |
| Conductor - Copper Str Size Range | 750 kcmil |
| Conductor - Material | ALUMINUM / COPPER |
| Conductor Size | 750 KCMIL |
| Conductor Type | CODE/FLEX |
| Wire Size | 750 KCMIL |
CERTIFICATIONS AND COMPLIANCE
| Certification - CSA Approved | Yes |
| Certification - cULus | No |
| Certification - ETL | No |
| Certification - UL Recognized | No |
| Industry Standard(s) | UL 486A-486B |
| Standards - Industry Standards Met | UL 486A-486B |
| Standards - RoHS Compliance Status | CM |
| UL Listed | Yes |
OPERATIONAL
| Temperature Rating | 194 |
CONFIGURATION
| Connector Type | INLINE PIN |
| Physical Attribute - Number of Crimps Required | 3 |
LOGISTICS
| Carton Quantity | 6 |
| Minimum Pack Quantity | 1 |
| Pallet Quantity | 1776 |
Product Datasheet
AYP750
AYP750
