B075 - Schneider Electric - 75A 240V Square D Circuit Breaker 2Pole
Industrial Circuit Breaker Enclosures are designed to be tough, reliable and provide exceptional performance in the most grueling conditions. Provides a dead front housing for circuit breakers, molded case switches, and motor circuit protectors to prevent personnel from accidentally contacting energized parts. Designed to meet or exceed UL 50 requirements for specific environmental conditions. Allow breaker operation without removing cover. These units are UL Listed and CSA Certified. Square D equipment with "R'' or "RB'' suffix, designated NEMA 3R rainproof construction, utilizes bolt-on hubs listed below. "RB'' devices will accept 3/4 in. through 2- 1/2 in. bolt-on hubs without the use of reducers. Off-center conduit thread openings and elongated mounting holes provide quick and easy adjustment to eliminate costly conduit offsets and bends. Load Center Hub, 0.75 in, rainproof, for RB devices is a conduit entry, and is used for conduit installation. This bolt-on accessory has a UL listed rating. The dimensions are 1.38 mm(H)4.44 mm(W)3.09 mm(D). This product comes with an 18 month warranty.
GENERAL SPECIFICATIONS
Main
| Hub type |
B |
| Product or Component Type |
Hub |
Complementary
| Cable entry |
Conduit entry 0.75 in (19.05 mm) |
| Depth |
3.09 in (78.49 mm) |
| Height |
1.24 in (31.50 mm) |
| Width |
4.44 in (112.78 mm) |
Environment
| Product Certifications |
UL Listed |
Ordering and shipping details
| Category |
US1DE1A00032 |
| Discount Schedule |
DE1A |
| GTIN |
785901459415 |
| Returnability |
Yes |
| Country of origin |
IN |
Packing Units
| Unit Type of Package 1 |
PCE |
| Nbr. of units in pkg. |
1 |
| Package 1 Height |
1.300 in (3.302 cm) |
| Package 1 Width |
4.600 in (11.684 cm) |
| Package 1 Length |
6.500 in (16.510 cm) |
| Package weight(Lbs) |
4.800 oz (136.078 g) |
| Unit Type of Package 2 |
CAR |
| Number of Units in Package 2 |
10 |
| Package 2 Height |
8.300 in (21.082 cm) |
| Package 2 Width |
5.000 in (12.700 cm) |
| Package 2 Length |
13.700 in (34.798 cm) |
| Package 2 Weight |
3.459 lb(US) (1.569 kg) |
| Unit Type of Package 3 |
PAL |
| Number of Units in Package 3 |
1200 |
| Package 3 Height |
34.000 in (86.360 cm) |
| Package 3 Width |
42.000 in (106.680 cm) |
| Package 3 Length |
42.000 in (106.680 cm) |
| Package 3 Weight |
468.000 lb(US) (212.281 kg) |
