B4.85 - Schneider Electric - Square D Overload Relay Thermal Unit
Linergy NEMA fuse holders are panel mount fuse holders that will accept class H, R, CC, M, and J fuses up to 200 Amps. This three pole fuse holder will accept class R fuses. The rating of the fuse can be up to 100 Amps with a 600 V maximum rating. The box lug connectors will accept 6 to 2/0 AWG (16 to 50 mm2) solid or stranded copper or aluminum wire. Fuse clips are made of one piece aluminum with copper spring that is tin plated. The fuse clips are reinforced for a better connection. The fuse holder base is made of general purpose phenolic. AIC Rating in accordance with UL512 is 20,000 Amp. This fuse holder is UL listed and CSA certified
GENERAL SPECIFICATIONS
Main
| Range of Product |
B |
| Thermal overload type |
Melting alloy |
| Motor tripping class |
20 |
Ordering and shipping details
| Category |
US10CP121781 |
| Discount Schedule |
0CP1 |
| GTIN |
785901587408 |
| Returnability |
Yes |
| Country of origin |
MX |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
0.80 in (2.032 cm) |
| Package 1 Width |
1.10 in (2.794 cm) |
| Package 1 Length |
2.40 in (6.096 cm) |
| Package 1 Weight |
0.640 oz (18.144 g) |
| Unit Type of Package 2 |
CAR |
| Number of Units in Package 2 |
6 |
| Package 2 Height |
0.80 in (2.032 cm) |
| Package 2 Width |
3.40 in (8.636 cm) |
| Package 2 Length |
4.80 in (12.192 cm) |
| Package 2 Weight |
4.32 oz (122.47 g) |
PRODUCT DATASHEET
B4.85_Product Datasheet
