B40.0 - Schneider Electric - Square D Overload Relay Thermal Unit
Linergy NEMA sectional terminal blocks are for terminating wires in a control panel and are designed to NEMA standards. This terminal block has a flat terminal connector for use with wires that have ring or spade connectors on the end of the wires. Solid or stranded copper wires from #22 through #12 AWG can be used with this terminal block. Each terminal is approved for use with 1 or 2 #12 wires, 1 or 2 #14 wires, 1 or 2 #16 wires, 1 or 2 #18 wires, 1 or 2 #20 wires, or 1 or 2 #22 wires. The nylon block is molded in the natural color of nylon (off white). This block is UL component recognized and CSA certified for up to 40 Amps and up to 600 VAC or VDC.
GENERAL SPECIFICATIONS
Main
| Range of Product |
B |
| Thermal overload type |
Melting alloy |
| Motor tripping class |
20 |
Ordering and shipping details
| Category |
US10CP121781 |
| Discount Schedule |
0CP1 |
| GTIN |
785901587590 |
| Returnability |
Yes |
| Country of origin |
MX |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
0.80 in (2.032 cm) |
| Package 1 Width |
1.20 in (3.048 cm) |
| Package 1 Length |
2.50 in (6.35 cm) |
| Package 1 Weight |
0.640 oz (18.144 g) |
| Unit Type of Package 2 |
CAR |
| Number of Units in Package 2 |
6 |
| Package 2 Height |
0.80 in (2.032 cm) |
| Package 2 Width |
3.50 in (8.89 cm) |
| Package 2 Length |
5.00 in (12.7 cm) |
| Package 2 Weight |
4.160 oz (117.934 g) |
| Unit Type of Package 3 |
PAL |
| Number of Units in Package 3 |
360 |
| Package 3 Height |
40.00 in (101.6 cm) |
| Package 3 Width |
40.00 in (101.6 cm) |
| Package 3 Length |
48.00 in (121.92 cm) |
| Package 3 Weight |
371.0008 lb(US) (168.283 kg) |
PRODUCT DATASHEET
B40.0_Product Datasheet
