B50.0 - Schneider Electric - Square D Overload Relay Thermal Unit
Linergy NEMA sectional terminal blocks are for terminating wires in a control panel and are designed to NEMA standards. This terminal block has a box lug connector for use with solid or stranded copper wires from #6 AWG through 250 kcmil. Each box lug terminal is approved for use with various wire combinations. Each lug accepts one 250 kcmil, 4/0, 3/0, 2/0, 1/0, #1 AWG, #2 AWG, or #4 AWG wire. The nylon block is molded in the natural color of nylon (off white). This block is UL component recognized for up to 255 Amps and CSA certified for up to 280 Amp. Both UL and CSA have the block rated at up to 600 VAC or VDC.
GENERAL SPECIFICATIONS
Main
| Range of Product |
B |
| Thermal overload type |
Melting alloy |
| Motor tripping class |
20 |
Ordering and shipping details
| Category |
US10CP121781 |
| Discount Schedule |
0CP1 |
| GTIN |
785901587613 |
| Returnability |
Yes |
| Country of origin |
MX |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
0.80 in (2.032 cm) |
| Package 1 Width |
1.20 in (3.048 cm) |
| Package 1 Length |
2.40 in (6.096 cm) |
| Package 1 Weight |
0.640 oz (18.144 g) |
| Unit Type of Package 2 |
CAR |
| Number of Units in Package 2 |
6 |
| Package 2 Height |
0.80 in (2.032 cm) |
| Package 2 Width |
3.50 in (8.89 cm) |
| Package 2 Length |
4.80 in (12.192 cm) |
| Package 2 Weight |
3.680 oz (104.326 g) |
PRODUCT DATASHEET
B50.0_Product Datasheet
