Description
BAB3015H - Eaton Cutler Hammer - 15A 240 V Three-Pole BAB Thermal Magnetic Circuit Breakers
The Eaton BAB3015H is a three-pole Quicklag bolt-on thermal-magnetic circuit breaker rated at 15 A for 240 V service, with a 10 kA interrupt capacity. This compact unit is non-interchangeable and designed for robust industrial applications. UL/CSA-certified and quick to install, it’s ideal for panelboard protection in three-phase systems.
GENERAL SPECIFICATIONS
| Product Name |
Eaton BAB thermal magnetic circuit breaker
|
| Catalog Number |
BAB3015H
|
| UPC |
786679303153
|
| Product Length/Depth |
3.8 in
|
| Product Height |
4.9 in
|
| Product Width |
3.2 in
|
| Product Weight |
1 lb
|
| Certifications |
UL Listed
CSA Certified |
| Catalog Notes |
HACR rated
|
| Product Type |
Thermal magnetic circuit breakers
|
PHYSICAL ATTRIBUTES
| Circuit breaker type |
BAB
|
| Number of poles |
Three-pole
|
| Type |
Quicklag industrial thermal-magnetic circuit breaker
|
PERFORMANCE RATINGS
| Amperage Rating |
15 A
|
| Interrupt rating |
10 kAIC
|
| Trip Type |
Non-Interchangeable
|
| Voltage rating |
240 V - 240 V
|
MISCELLANEOUS
| Special features |
Bolt-on mounting
|
PRODUCT DATASHEET
