Description
BC350M - Appleton - RIGID CONDUIT OUTLRT BODY AND COVER
ZINC ELECTROPLATED/CHROMATE/EPOXY POWDER COATED MALLEABLE IRON (BODY), STAINLESS STEEL (SCREW) MATERIAL; 31.38 INCH LENGTH X 5.63 INCH WIDTH X 7.19 INCH HEIGHT SIZE; IMC/THREADED RIGID METAL CONDUIT USED ON; 3-1/2 INCH HUB SIZE; THREADED INSTALLATION; C CONFIGURATION; 2 HUB(S); UL 514B, CSA C22.2 APPROVAL; STRAIGHT HUB LOCATION; SIDE ACCESS OPENING; UNILETS[R] BRAND; WIRE SIZE (3) 900 MCM; CAPACITY 830 CUBIC INCH; ENCLOSURE RATING CLASS I DIV 2; APPLICATION COMMERCIAL/INDUSTRIAL, HAZARDOUS LOCATION; APPLICABLE STANDARD NEC/CEC, NEMA FB-1
GENERAL SPECIFICATIONS
| Access Opening | Side |
| Configuration | C |
| Hub Location | Straight |
| Number of Hubs | 2 |
| Hub Size | 3-1/2 Inch |
| Size | 31.38 Inch Length x 5.63 Inch Width x 7.19 Inch Height |
| Installation | Threaded |
| Material | Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Stainless Steel (Screw) |
| Approval | UL 514B, CSA C22.2 |
| Used On | IMC/Threaded Rigid Metal Conduit |
| Brand Name | Unilets® |
| Additional Information | Wire Size (3) 900 MCM; Capacity 830 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard NEC/CEC, NEMA FB-1 |
