BLB125M - Appleton - 1-1/4 Inch LB Conduit Body Epoxy Coated Iron
Roll over image to zoom in Click on image to zoom
BLB125M - Appleton - 1-1/4 Inch LB Conduit Body Epoxy Coated Iron

BLB125M - Appleton - 1-1/4 Inch LB Conduit Body Epoxy Coated Iron

AppletonSKU: APPBLB125M
Price:
$162.13
Stock:
10 In Stock and Ready To Ship
Same Day Shipping

Description

Specifications

Access Opening Back
Configuration LB
Hub Location 90 Degree
Number of Hubs 2
Hub Size 1-1/4 Inch
Size 9.69 Inch Length x 2.38 Inch Width x 4.75 Inch Height
Installation Threaded
Material Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Stainless Steel (Screw)
Approval UL 514B, CSA C22.2
Used On IMC/Threaded Rigid Metal Conduit
Brand Name Unilets®
Additional Information Wire Size (3) 1/0 AWG; Capacity 48 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard NEC 6X/CEC, NEMA FB-1
Product Datasheet
BLB125M
