Description
C25DND330B - Eaton Cutler-Hammer - 30 Amp 3 Pole 600 Volt Magnetic Contactor
Eaton definite purpose contactor, Quick, 30A,208-240 Vac, 50/60 Hz, Open with metal mounting plate, 15-50A, two- and three-pole, 30A, Contactor, Three-pole, 40A, Screw/pressure plate and quick connect terminals (side-by-side), Non-reversing
GENERAL SPECIFICATIONS
|
PRODUCT NAME |
Eaton definite purpose contactor |
|
CATALOG NUMBER |
C25DND330B |
|
UPC |
782116300617 |
|
PRODUCT LENGTH/DEPTH |
3.35 in |
|
PRODUCT HEIGHT |
2.5 in |
|
PRODUCT WIDTH |
2.4 in |
|
PRODUCT WEIGHT |
1.3 lb |
|
COMPLIANCES |
RoHS Compliant |
|
CERTIFICATIONS |
CSA Certified UL Recognized |
| Product Type |
Definite purpose contactor
|
PRODUCT SPECIFICATIONS
|
FRAME SIZE |
15-50 A, two-pole and three-pole |
|
TYPE |
Non-reversing |
|
INDUCTIVE FULL LOAD |
30 A |
|
MODEL |
Contactor |
|
CONNECTION |
Quick |
|
ENCLOSURE |
Open with a metal mounting plate |
|
TERMINALS |
Screw/pressure plate and quick connect terminals (side-by-side) |
|
AMPERAGE RATING |
30A |
|
RESISTIVE LOAD |
40 A |
|
NUMBER OF POLES |
Three-pole |
|
COIL |
208-240 Vac, 50/60 Hz |
