CG1250S - Appleton - 1/2" Steel Liquidtight Strain Relief Cord and Cable Connector
CG1250S is a 1″ hub, 90° liquid-tight strain relief cord connector from Appleton’s CG series, designed to provide secure sealing and mechanical protection for flexible cords in industrial environments. Constructed primarily from aluminum, it features a stainless steel cap or hardware that enhances corrosion resistance, making it suitable for harsher or corrosive environments. The connector includes a neoprene sealing grommet for strain relief, a steel/Teflon washer to prevent thread distortion, and is rated for NEMA 3R applications in both wet and dry locations. UL and CSA certified, it's ideal for use in hazardous locations including Class I, II, and III divisions.
GENERAL SPECIFICATIONS
- NEC/CEC Certifications and Compliances
- Suitable for use in: Class I, Division 2; Class II, Division 1 and 2; Class III,; NEMA 3R
- Aluminum Standard Materials
- Straight body: aluminum. 90° body: cast aluminum. Sealing grommet: neoprene. Washer: steel or Teflon. Wire mesh strain relief: stainless steel. Cap, cap on wire mesh: copperfree (4/10 of 1% or less) aluminum
- Steel Standard Materials
- Straight body and cap: machined steel. 90° body: malleable iron. Sealing grommet: neoprene. Washer: steel or Teflon. Wire mesh strain relief: stainless steel. Cap on wire mesh: zinc plated steel
- Optional Materials
- PVC coating available on select connectors. See catalog pages for details
