Description
General specifications
| Product Name | Eaton CSR main breaker |
| Catalog Number | CSR2125N |
| UPC | 782114019733 |
| Product Length/Depth | 3.1 in |
| Product Height | 3.1 in |
| Product Width | 2 in |
| Product Weight | 2.5 lb |
| Warranty | Limited lifetime |
| Certifications | UL 489 |
| Product Type | Main breaker |
Product specifications
| Used with | For use in Type ECC Unit Enclosures |
| Amperage Rating | 125 A |
| Voltage rating | 120/240 V |
| Circuit breaker frame type | CSR |
| Interrupt rating | 25 kAIC |
| Main circuit breaker | CH |
| Wire size | #2 AWG-300 kcmil |
| Number of poles | Two-pole |
| Type | Standard circuit breaker |
Product Datasheet
CSR2125N
CSR2125N
