Description
General specifications
| Product Name | Eaton Series C complete molded case circuit breaker |
| Catalog Number | FD2125L |
| UPC | 786679850725 |
| Product Length/Depth | 3.38 in |
| Product Height | 6 in |
| Product Width | 2.75 in |
| Product Weight | 4.5 lb |
| Warranty | Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first. |
| Certifications | UL Listed |
| Product Type | Molded case circuit breaker |
Product specifications
| Amperage Rating | 125 A |
| Voltage rating | 600 Vac, 250 Vdc |
| Trip Type | T186 |
| Circuit breaker type | FD |
| Circuit breaker frame type | Complete breaker |
| Series | Series C |
| Terminals | Line and load |
| Frame | F |
| Frequency rating | 50/60 Hz |
| Interrupt rating | 65 kAIC at 240 Vac 35 kAIC at 480 Vac |
| Number of poles | Two-pole |
