Description
General specifications
| Product Name | Eaton Type FDPW fusible panelboard switch |
| Catalog Number | FDPWT3222R |
| UPC | 786679651612 |
| Product Length/Depth | 26.4 in |
| Product Height | 10.3 in |
| Product Width | 8.1 in |
| Product Weight | 16.5 lb |
| Warranty | Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first. |
| Global Catalog | FDPWT3222R |
| Product Type | Fusible panelboard switch |
Product specifications
| Special features | FDPW fusible panelboard switch |
| Type | Fusible panelboard switch |
| Amperage Rating | Unit 1: 60A, Unit 2: 60A |
| Connection | Branch |
| HP rating - max | 15 hp at 240 Vac, 10 hp at 250 Vdc |
| Number of poles | Three-pole |
| Voltage rating | 240 Vac, 250 Vdc |
| Wire size | #14-1/0 AWG |
| Fuse class provision | Class R fuses |
| Interrupt rating | 200 kAIC at 240 Vac, 10 kAIC at 250 Vdc |
| Switch type | FDPW, twin, horizontal |
