CR306D002 - General Electric - 45 Amp 3 Pole 600 V Motor Starter

CR306D002 - General Electric - 45 Amp 3 Pole 600 V Motor Starter

The General Electric CR306D002 300-Line Motor Starter is a 600V 3 phase 45A 3 pole starter. It has a horsepower rating of HP @ 3 Phase - 208V 10 hp HP @ 3 Phase - 240V 15 hp HP @ 3 Phase - 480V 25 hp. This starter comes complete with a 115V coil. Heater Packs must be purchased separately. Every part Essential Electric sells is also backed by our industry-leading gold standard 2-year warranty.

TECHNICAL SPECIFICATIONS

General Information

Global Commercial Alias	306D002
Extended product type	306 Strtr,sz 2,3P,120Vac
Product ID	7GSP009225R0006
Catalog description	306 Strtr,sz 2,3P,120Vac 305 /306 / 309 Open
Long description	300 series full-voltage contactos & motor controllers has encapsulated coils. Availilbe in size 00-9, open or NEMA Type 1,12,3R, 4X enclosures and toolless contactor disassembly.



Materials Compliance

REACH information

False - does not contain substances > 0.1 mass percentage

Classification

Minimum order quantity	1 EA
UPC	783166358689

Dimensions

Product Width	5.5 in
Product Height	4.68 in
Product Net Depth / Length	9.12  in
Product Net Weight	8 lb

Packaging Information

Package Level 1 Units	1 piece
Package Level 1 Width	8.25 in
Package Level 1 Height	7.5 in
Package Level 1 Depth / Length	10.25 in
Package Level 1 Gross Weight	8.665 lb

Technique

Number of poles

3P

External classifications and standards

ETIM 9	EC001037 - Motor starter/motor starter combination
WEEE Category	5. Small equipment (no external dimension exceeding 50 cm)
WEEE B2C / B2B	business to business
CN8	85365040
UNSPSC	39121521
Electronic class	V11.1 : 27370905



PRODUCT DATASHEET

CR306D002
