CSR2150N - Eaton Cutler-Hammer - Plug-In 150 Amp 240 Volt 2 Pole Circuit Breaker
Eaton Type CSR Standard Circuit Breaker,Standard circuit breaker,150 A,25 kAIC,Two-pole,120/240 V,CH,#2 - 300 kcmil,CSR,For use in type ECC unit enclosures,Single-phase.
GENERAL SPECIFICATIONS
| Product Name |
Eaton CSR main breaker |
| Catalog Number |
CSR2150N |
| UPC |
782113098449 |
| Product Length/Depth |
5.3 in |
| Product Height |
3.52 in |
| Product Width |
4.2 in |
| Product Weight |
2.5 lb |
| Certifications |
UL 489 |
PRODUCT SPECIFICATIONS
| Used with |
For use in Type ECC Unit Enclosures |
| Type |
Standard circuit breaker |
| Amperage Rating |
150 A |
| Voltage rating |
120/240 V |
| Circuit breaker frame type |
CSR |
| Interrupt rating |
25 kAIC |
| Main circuit breaker |
CH |
| Wire size |
#2 AWG-300 kcmil |
| Number of poles |
Two-pole |
PRODUCT DATASHEET
