Description
E50AR1 - Eaton Cutler Hammer - 10A E50 Nema Heavy Duty Plug-In Limit Switch
E50 NEMA Limit Switch,Side Rotary,Spring Ret,14-250F(-10-121C),1NO-1NC,10A@240Vac,1A@250Vdc,Mech 10M Elec 1M cy full load,8000 cy/hr,Screw term,1/2NPT cond,NEMA 1,3,3S,4,4X,6,6P,13,IP67,Diec Zn,UL,CSA,CE.
GENERAL SPECIFICATIONS
| Product Name | Eaton E50 NEMA heavy duty plug-in limit switch |
| Catalog Number | E50AR1 |
| UPC | 782113289861 |
| Product Length/Depth | 4.22 in |
| Product Height | 2.25 in |
| Product Width | 1.54 in |
| Product Weight | 1.1 lb |
| Compliances | RoHS Compliant CE Marked |
| Certifications | CSA Certified UL Listed |
| Product Type | Heavy-duty plug-in limit switch |
PRODUCT SPECIFICATIONS
| Type | Assembly |
| Contact Rating | 10A at 240 Vac, 1A at 250 Vdc |
| Enclosure material | Die cast zinc |
| Accessories | E50DR1 |
| Actuator | Side rotary |
| Connection | Screw terminal |
| Contact configuration | 1 NO-1 NC |
| Series | E50 heavy duty plug in |
| Operating temperature - max | 200 degF |
| Operating temperature - min | 10 degF |
| Environmental rating | NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67 |
| Maximum AC current | 10 A continuous |
| Maximum DC current | 1 A |
