Description
E50DR1 - Eaton Cutler Hammer - E50 Nema Heavy Duty Plug-In Limit Switch
The E50DR1 is a standard side rotary operating head with a spring-return mechanism designed for E50 series limit switches. It requires 5° to activate, offering a rugged die-cast zinc construction and operating across NEMA 1 to 6P and IP67 environmental ratings, with UL and CSA recognition.
GENERAL SPECIFICATIONS
| Product Name |
Eaton E50 NEMA heavy duty plug-in limit switch
|
| Catalog Number |
E50DR1
|
| UPC |
782113290560
|
| Product Length/Depth |
1.05 in
|
| Product Height |
2.46 in
|
| Product Width |
1.54 in
|
| Product Weight |
0.3 lb
|
| Compliances |
RoHS Compliant
CE Marked |
| Certifications |
CSA Certified
UL Recognized UL Listed |
PRODUCT SPECIFICATIONS
| Enclosure material |
Die cast zinc
|
| Actuator |
Side rotary, standard spring return
|
| Series |
E50 heavy duty plug in
|
| Operating temperature - max |
200 °F
|
| Operating temperature - min |
10 °F
|
| Environmental rating |
NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
|
