C306GN3B - Eaton Cutler-Hammer - 60-79A 3 Pole Freedom NEMA Overload Relay
Eaton Freedom NEMA overload relay, 60 - 79A, Three-pole, NEMA Size 1, 2, IEC Size G-K , Panel Mounted or Starter Replacement mounting
GENERAL SPECIFICATIONS
| Product Name |
Eaton Freedom NEMA overload relay
|
| Catalog Number |
C306GN3B
|
| UPC |
782113973241
|
| Product Length/Depth |
5.25 in
|
| Product Height |
4.5 in
|
| Product Width |
4.5 in
|
| Product Weight |
0.94 lb
|
| Certifications |
UL Listed
CSA Certified |
| Catalog Notes |
Series B overload relays have load lugs built into relay base and will only accept Series B heater packs. These relays can be directly attached to a contactor or they can be DIN rail or panel mounted using an adapter.
|
| Product Type |
Overload relay
|
PRODUCT SPECIFICATIONS
| Amperage Rating |
60-79A
|
| Design |
NEMA, IEC
|
| Frame size |
NEMA Size 1, 2, IEC Size G-K
|
| Mounting |
Panel
|
| Number of poles |
Three-pole
|
| Special features |
Heaters required
|
| Trip Type |
Thermal
|
| Type |
Freedom NEMA
|
