ED2175L - Eaton Cutler-Hammer - Feed-Thru 175 Amp 2 Volt 2 Pole Molded Case Circuit Breaker
Eaton Series C complete molded case circuit breaker, Series C, F-frame molded case circuit breaker, 175 A, Two-pole, Line and load terminals, Fixed thermal magnetic trip, ED breaker, 65 kAIC at 240 Vac.
GENERAL SPECIFICATIONS
| Product Name |
Eaton Series C complete molded case circuit breaker |
| Catalog Number |
ED2175L |
| UPC |
786679454121 |
| Product Length/Depth |
3.38 in |
| Product Height |
6 in |
| Product Width |
2.75 in |
| Product Weight |
2.9 lb |
| Certifications |
UL Listed |
PRODUCT SPECIFICATIONS
| Amperage Rating |
175 A |
| Voltage rating |
240 Vac, 125 Vdc |
| Trip Type |
T186 |
| Circuit breaker type |
ED |
| Circuit breaker frame type |
Complete breaker |
| Series |
Series C |
| Terminals |
Line and load |
| Frame |
F |
| Frequency rating |
50 to 60 Hz |
| Interrupt rating |
65 kAIC at 240 Vac |
| Number of poles |
Two-pole |
