Description
EGB2070FFG - Eaton Cutler-Hammer - 70 Amp 2 Pole 480 Volt Feed Thru Molded Case Circuit Breakers
Eaton Series G molded case circuit breaker, EG-frame, EG, Complete breaker, Fixed thermal, fixed magnetic trip type, Two-pole, 70A, 600Y/347 Vac, 25 kAIC at 240 Vac, 18 kAIC at 480 Vac, Line and load, 50/60 Hz.
GENERAL SPECIFICATIONS
| Product Name |
Eaton Series G complete molded case circuit breaker
|
| Catalog Number |
EGB2070FFG
|
| UPC |
786685018522
|
| Product Length/Depth |
2.99 in
|
| Product Height |
5.5 in
|
| Product Width |
2 in
|
| Product Weight |
2 lb
|
| Compliances |
CE Marked
|
| Certifications |
IEC Rated
UL Listed CSA Certified |
| Product Type |
Molded case circuit breaker
|
PRODUCT SPECIFICATIONS
| Amperage Rating |
70A
|
| Voltage rating |
600Y/347 Vac
|
| Trip Type |
T186
|
| Circuit breaker type |
EG
|
| Circuit breaker frame type |
Complete breaker
|
| Series |
Series G
|
| Terminals |
Line and load
|
| Frame |
EG
|
| Frequency rating |
50/60 Hz
|
| Interrupt rating |
25 kAIC at 240 Vac
18 kAIC at 480 Vac |
| Number of poles |
Two-pole
|
| Type |
Complete breaker
|
PRODUCT DATASHEET
