Description
EGB3060FFG - Eaton Cutler-Hammer - 60 Amp 3 Pole 480 Volt Molded Case Circuit Breakers
Eaton Series G molded case circuit breaker, EG-frame, EG, Complete breaker, Fixed thermal, fixed magnetic trip type, Three-pole, 60A, 600Y/347 Vac, 25 kAIC at 240 Vac, 18 kAIC at 480 Vac, Line and load, 50/60 Hz.
GENERAL SPECIFICATIONS
| Product Name | Eaton Series G complete molded case circuit breaker |
| Catalog Number | EGB3060FFG |
| UPC | 782114876374 |
| Product Length/Depth | 2.99 in |
| Product Height | 5.5 in |
| Product Width | 3 in |
| Product Weight | 2.88 lb |
| Compliances | CE Marked |
| Certifications | CSA Certified IEC Rated UL Listed |
| Product Type | Molded case circuit breaker |
PRODUCT SPECIFICATIONS
| Amperage Rating | 60 A |
| Voltage rating | 600Y/347 Vac |
| Trip Type | T186 |
| Circuit breaker type | EG |
| Circuit breaker frame type | Complete breaker |
| Series | Series G |
| Terminals | Line and load |
| Frame | EG |
| Frequency rating | 50/60 Hz |
| Interrupt rating | 25 kAIC at 240 Vac 18 kAIC at 480 Vac |
| Number of poles | Three-pole |
| Type | Complete breaker |
