EGB34100SA - Square D - 100A 480Y/277VAC 3-Pole 65kA Bolt-On Shunt Trip Mini Circuit Breaker
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 100A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 65 kA max interrupt rating at 120 VAC. This device has a hold current of 1000A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 2300A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes a shunt trip. This breaker was calibrated for 40 degrees C. HACR rated.
GENERAL SPECIFICATIONS
| Range | 125 A Frame EDB-EGB-EJB |
|---|---|
| Product Type | Miniature circuit-breaker |
| Device Short Name | EGB |
| Module Type | E-Frame |
| Trip Unit Rating | 2300 A |
| Rated Current | 100 A |
|---|---|
| Maximum Operating Voltage | 480Y/277 V AC |
| AWG Gauge | AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper |
| Breaking Capacity | 35 kA 277 V AC 65 kA 240 V AC 35 kA 480Y/277 V AC 65 kA 120 V AC 65 kA 120/240 V AC |
| Circuit Breaker Application | HACR rated |
| Electrical Connection | Lugs aluminium |
| Holding Current | 1000 A |
| Local Signalling | Trip indicator |
| Mounting Mode | Bolt-on |
| Number of Poles | 3 |
| Number of Spaces | 4 |
| Number of Spaces Required | 4 |
| Product Destination | NF panelboard |
| Protect Type | Overload Short-circuit |
| Device Composition | Shunt trip |
| Trip Unit Technology | Thermal-magnetic |
| Breaking Capacity Code | G |
| Tightening Torque | 34.5 lbf.in (3.9 N.m) 0.004…0.009 in² (2.5…6 mm²) (AWG 14...AWG 10) 49.6 lbf.in (5.6 N.m) 0.02…0.1 in² (10…70 mm²) (AWG 8...AWG 2/0) |
| Height | 5.66 in (143.76 mm) |
| Width | 3.92 in (99.57 mm) |
| Depth | 4.05 in (102.87 mm) |
| Product Weight | 4 lb(US) (1.8 kg) |
| Product Certifications | cULus |
|---|---|
| Ambient Air Temperature for Operation | 104 °F (40 °C) |
| Category | US10DE200936 |
|---|---|
| Discount Schedule | 0DE2 |
| GTIN | 785901159483 |
| Returnability | No |
| Country of origin | MX |
| Unit Type of Package 1 | PCE |
|---|---|
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 6.300 in (16.002 cm) |
| Package 1 Width | 6.200 in (15.748 cm) |
| Package 1 Length | 9.900 in (25.146 cm) |
| Package weight(Lbs) | 4.17 lb(US) (1.89 kg) |
| Compliance | TAA Compliant |
|---|
