Description
EXLK236 - Appleton - 3/4" x 36" Flexible Coupling Explosion-Proof Fitting
This 3/4 inch x 36 inch UNILETS Flexible Coupling is explosion-proof and watertight, built for use in hazardous locations including Class I (Groups A, B, C, D), Class II (Groups E, F, G), and Class III areas. It features a durable bronze outer braid and a brass inner core with an insulating liner, ensuring strength, flexibility, and electrical insulation. Designed for rigid and IMC conduit systems, it includes one removable male nipple and one removable union, making it ideal for areas with vibration, movement, or complex bends.
GENERAL SPECIFICATIONS
- NEC/CEC Certifications and Compliances
- 1/2 and 3/4 Sizes: Class I, Groups A, B, C, D; Class II, Groups E, F, G; Class III
- NEC/CEC Certifications and Compliances
- 1 Size: Class I, Groups C, D; Class II, Groups E, F, G; Class III
- NEC/CEC Certifications and Compliances
- 1-1/4 thru 4 Sizes: Class I, Group D; Class II, Groups E, F, G; Class III
- ATEX Certifications and Compliances
- Stainless steel 1/2 thru; 2 Sizes: Ex II2 GD; Ex d IIC Gb; Ex t IIIC Db; IP66
- Standard Materials
- 1/2 thru 2: outer bronze braid, inner brass core with insulating liner, brass end fittings. 2-1/2 thru 4: outer stainless steel braid, inner stainless steel core with insulating liner, stainless steel end fittings
- Standard Finishes
- Natural finish
- Options
- 1/2 through 2 available in stainless steel (suffix -SS). 1/2 through 1 EXLK stainless steel union (suffix -SU). 1/2 through 1 stainless steel nipple (suffix -NS). Custom lengths available (contact your local sales representative)
PRODUCT DATASHEET
